YINGANG XR-5

Dirt Bikes & Enduro — available for OEM/ODM customization and CKD/SKD/CBU supply.

Dirt Bikes & Enduro

XR-5

  • OEM/ODM customization available
  • CKD / SKD / CBU supply options
  • Export documentation support

⚡ We reply to every inquiry within 12 hours on working days.

Model Description

The XR-5 is a water-cooled 125cc enduro with EFI and a 6-speed transmission — with ABS and CBS available as options. Long-travel suspension, 250mm ground clearance and a 15L fuel tank make it ready for rough terrain and long days off the road.

Engine options from 125cc to 300cc are available for different market requirements. Like every YINGANG model, the XR-5 can be customized for your market — colors, decals, packaging and certification requirements. CKD, SKD and CBU supply options are available.

Technical Specifications

ENGINE TYPEYG125 cc; WATER-COOLED, 4-STROKE, 4-VALVES
MAX POWER11.0 kW @ 9,750 rpm
MAX TORQUE11.5 N·m @ 8,000 rpm
FUEL SYSTEMEFI/CARBURETOR
START SYSTEMELECTRIC
TRANSMISSION6 GEARS
DIMENSION2,000 × 970 × 1,410 mm
WHEELBASE1,290 mm
SEAT HEIGHT880 / 950 mm
GROUND CLEARANCE250 mm
DRY WEIGHT148 kg
MAX SPEED99 km/h
SUSPENSIONFR/RR: INVERTED/MONO SHOCK
BRAKEFR/RR: DISC/DISC
FUEL TANK15 L
OPTIONS125~300 cc/AIR/OIL/ABS/CBS/BOX/CARPLAY
LOADING75 units / 40HQ (CBU)

Specifications vary by market version and customization. Contact us for the full spec sheet of the XR-5 for your target market.

Product Details
